NX PZ3 Standard Condensing Units for Twin Applications
Enquire Now
New PZ3 NX Series for 2020
NX Series with R32 Refrigerant has been developed to meet the demands of easy refurbishment with 3 wired power supply and communications.
Also new series are integrated with IoT solutions as well as nanoe™ X that improves indoor air quality.
Specification and information for Panasonic Standard condensing units to allow Twin Combinations
Note – twin only available on 10kW – 14kW Models
Sales information Sales information 2 Logicool technical bulletin Service manuals Installation manual IU Dimensions Fault codes
| Outdoor Unit Technical Data | |||||||
| Combinations | Single | Single and Twin | |||||
| Model | U-36PZ3E5 | U-50PZ3E5 | U-60PZ3E5 | U-71PZ3E5 | U-100PZ3E5(8) | U-125PZ3E5(8) | U-140PZ3E5(8) |
| Height (mm) | 619 | 619 | 695 | 695 | 996 | 996 | 996 |
| Width (mm) | 824 | 824 | 875 | 875 | 980 | 940 | 980 |
| Depth (mm) | 299 | 299 | 320 | 320 | 370 | 370 | 370 |
| Weight (kG) | 32 | 35 | 42 | 50 | 90 | 94 | 94 |
| Airflow (m3/min) Cool / Heat | 33.60 / 34.00 | 32.70 / 31.90 | 42.60 / 41.50 | 44.70 / 45.90 | 76.00 / 70.00 | 86.00 / 78.00 | 89.00 / 83.00 |
| Sound Pressure Cool/Heat Hi (dBA) | 47 / 47 | 46 / 46 | 47 / 48 | 48 / 49 | 52 / 52 | 55 / 55 | 56 / 56 |
| Sound Power Cool/Heat Hi (dBA) | 64 / 66 | 64 / 64 | 64 / 65 | 66 / 68 | 70 / 70 | 73 / 73 | 74 / 74 |
| Liquid (mm(inches)) | 6.35 (1/4) | 6.35 (1/4) | 6.35 (1/4) | 6.35 (1/4) | 9.52 (3/8) | ||
| Gas (mm(inches)) | 12.70 (1/2) | 12.70 (1/2) | 12.70 (1/2) | 15.88 (5/8) | |||
| Max Pipe Run (m) | 15 | 20 | 30 | 40 | 50 | 50 | 50 |
| Max Pipe Lift (m) | 15 (15 if condenser is lower than IU) | 20 (15) | 30 | 30 | 30 | ||
| Pre-charged to (m) | 7.5 | 7.5 | 7.5 | 10 | 30 | 30 | 30 |
| Standing Charge (kG) | 0.87 | 1.14 | 1.15 | 1.32 | 2.40 | 2.80 | 2.80 |
| Additional Charge/m (g) | 10 | 15 | 15 | 17 | 45 | 45 | 45 |
| Refrigerant | R32 | ||||||
| Phase | Single | Single (Three) | |||||
| Power Supply to | Outdoor | ||||||
| Max Run Current (A) Cool | 3.85 | 5.95 | 7.45 | 10.00 | 12.10 (4.10) | 16.30 (5.45) | 20.40 (6.80) |
| Max Run Current (A) Heat | 3.35 | 5.05 | 6.20 | 7.80 | 9.25 (3.15) | 13.10 (4.40) | 15.60 (5.25) |
| Fuse Rating (A) | 16 | 16 | 20 | 20 | 25 (16) | 32 (16) | 32 (16) |
| Interconnecting | 3 Core plus earth |
||||||
| Twin Pipe Kit | Twin Combination Not Possible | CZ-P224BK2BM | |||||
Note that size 36 to 71 models do not allow Twin connection
Compatible products
This new series has been developed with 3 wired power supply and communication. It makes it simple and easy to replace old systems with 3 wire connections, which is prevalent in many systems.
Features and Benefits
- New 3 wire system for 2020
- New 3.5 and 5.0KW Standard Inverter models
- Flexible control option with IoT integration
- Reduced Pipe Sizing
- nanoe™ X indoor air quality (check indoor unit compatibility)
- Auto restart after power failure
- Auto changeover
- Twin split options
- ErP Compliant
- Cooling to -10°C
- Heating to -15°C
- R22 Replacement Technology
Optional Controls and Accessories (Outdoor Unit only)
- PAW-WTRAY – Tray for condenser water compatible with outdoor
elevation platform - PAW_GRBDSE20 – Outdoor base ground support for noise and vibration
absorption - PAW-GRDST40 – Outdoor elevation platform 400 x 900 x 400mm
- CZ-140DRS1 Drain Kit
- CZ-P224BK2BM for Twin-Split Application
Power/Wiring
New Panasonic NX systems simply require power to condensing unit and then a 3 core plus earth connection between outdoor unit and indoor unit.
Single Split
Twin Split
Group Control
Addressing Group Control Systems
Piping
CZ-P224BK2BM Pipe Kit required for all PAC-i NX Standard Twin Split installations from 10.0kW up to 14kW (sizes below this cannot have twin connectivity)
